PNEUMATIC / STRAIGHT THROUGH COUPLER



SPECIFICATIONS


VALVELESS STRUCTURE SUITS VISCOUS FLUIDS !

*  Various body materials, sizes and fitting type

*  Valveless construction greatly reduces pressure loss and enables high flow rate.

*  Suitable for viscous fluids (Such as grease).

*  Available in various standard body materials, sizes & fitting types to cope with a     wide variety of applications and conditions.

INTERCHANGEABILITY

Provided they are the same size, sockets and plugs can be interconnected irrespective of the type of fittings.



SPECIFICATIONS
Body Material CS (Chrome-Plated) Brass SS304 / 316
Size 1/8" , 1/4", 3/8", 1/2", 3/4", 1", 1 1/4", 1 1/2", 2"
Working Pressure kgf/cm2 75* 50* 75*
Pressure Resistancce Kgf/cm2 102* 75* 102*
Packing Material NBR, Viton (Optional), Silicon (Optional)

Through socket male Dimensions(mm)
Model No Size L A Hex C D
TSM 1 1/8" 30 9 Hex.14   17.5
TSM 2 1/4" 42 13 Hex.19   24
TSM 3 3/8" 46 13 Hex.23   28
TSM 4 1/2" 56 17 Hex.29   35
TSM 6 3/4" 65 19 Hex.38   45
TSM 8 1" 76 22 Hex.50   58
TSM 10 1 1/4" 86 25 face54*$62   69
TSM 12 1 1/2"  95 25 face58*$68   75
TSM 16 2" 108 29 face77*$82   98

TPM Through plug male
TSM 1 1/8" 32 9 Hex.12 15.5
TSM 2 1/4" 38 13 Hex.17 18
TSM 3 3/8" 43 13 Hex.19 21
TSM 4 1/2" 52 17 Hex.22 24
TSM 6 3/4" 59 19 Hex.32 28
TSM 8 1" 73 22 Hex.41 36
TSM 10 1 1/4" 83 23 Hex.50 39
TSM 12 1 1/2"  93 26 Hex.54 45
TSM 16 2" 102 27 face70*$80 51

TSH Through socket hose
Model No Size L A H C D
TSH -1 1/8" 40 20 16   17.5
TSH -2 1/4" 55 29 22   24
TSH -3 3/8" 62 32 25   28
TSH -4 1/2" 74 39 32   35
TSH -6 3/4" 90 48 40   45
TSH -8 1" 102 57 52   58
TSH -10 1 1/4" 117 70 64   69
TSH -12 1 1/2"  128 75 70   75
TSH -16 2" 141 80 90   98

TPH Through plug Hose
TPH-1 1/8" 41 20 12 15.5
TPH-2 1/4" 53 29 14 18
TPH-3 3/8" 60 32 18 21
TPH-4 1/2" 70 39 22 24
TPH-6 3/4" 84 48 28 28
TPH-8 1" 105 57 40 36
TPH-10 1 1/4" 121 70 48
TPH-12 1 1/2"  132 75 55 45
TPH-16 2" 142 80 70 51

TSF Through Socket Female
TSF-1 1/8" 27 9 Hex.14   17.5
TSF-2 1/4" 32 13 Hex.19   24
TSF-3 3/8" 35 13 Hex.23   28
TSF-4 1/2" 42 17 Hex.29   35
TSF-6 3/4" 48 19 Hex.38   45
TSF-8 1" 59 22 Hex.50   58
TSF-10 1 1/4" 64 23 Face54*$62   69
TSF-12 1 1/2"  71 25 face58*$68   75
TSF-16 2" 80 27 face77*$82   98

TPF Through Plug Female
TPF-1 1/8" 26 3 Hex.14 17.5
TPF-2 1/4" 34 13 Hex.17 18
TPF-3 3/8" 38 13 Hex.21 21
TPF-4 1/2" 45 17 Hex.29 24
TPF-6 3/4" 51 19 Hex.35 28
TPF-8 1" 60 22 Hex.41 36
TPF-10 1 1/4" 64 25 Hex.54 39
TPF-12 1 1/2"  75 25 Hex.58 45
TPF-16 2" 83 29 face77*$82 51
